Pressure testing
Pressure Test Pump Units
Werner pressure-test units give workshops, maintenance teams and field technicians controlled pressure for proof testing, certification and fault finding. The manual range works without external power and reaches up to 1,000 bar; the 45 kW electric range adds continuous-duty output and multiple pressure-flow combinations. Both are engineered for clear control, practical mobility and dependable service in demanding industrial environments.
Product overview
Built to endure. Engineered to perform.
A reliable pressure test depends on control, visibility and a system matched to the component. Werner offers compact hand-operated units for independent field work and a mobile electric range for higher-throughput industrial testing.
Manual certainty, wherever the job is
The hand-operated range needs no external power and uses a precision needle release valve for fine pressure adjustment and safe depressurisation. Lightweight aluminium construction, bronze and stainless-steel internals, a 20 L tank, pressure gauge and 2 m high-pressure hose create a portable system for water, hydraulic oil and approved specialist fluids.
Electric output for sustained testing
The 45 kW, 380 V trolley unit uses an open protective frame, heavy-duty wheels and a pulley-driven transmission. Four pump configurations balance pressure and flow from 100 bar at 21-82 L/min through to 1,000 bar at 5-20 L/min, with pressure regulation, relief protection, emergency shut-off and electrical overload protection.
Test with a system built for industrial reality
Applications include pipelines, valves, vessels, hoses, boilers, fire extinguishers and industrial components. Built and supported in South Africa, these units combine straightforward operation with the durability needed for African workshops and field sites – a standard equally valuable to testing teams anywhere in the world.
Manual test pressure up to 1,000 bar without external power
Manual models for boiler, valve, pipeline, hose and extinguisher testing
45 kW electric configurations from 100 to 1,000 bar
Electric flow ranges from 5-20 L/min at 1,000 bar to 21-82 L/min at 100 bar
Pressure regulation, relief protection and emergency depressurisation
Portable trolley or compact manual formats for workshop and site use
Optional calibrated gauges, longer hoses, adaptors and protective enclosures
How the system is defined
Performance starts with the duty.
Werner technical sales matches the complete unit to the material, environment, mounting and working cycle. Final specifications remain subject to engineering confirmation.
- Controlled pressure generation for testing duties
Configuration options
A complete working system, not a catalogue code.
Select the points you want to discuss. Your choices will be carried into the product enquiry as a grouped configuration brief.
Define the duty
Material, pipe or surface, environment, access, distance and working cycle.
Set the performance
Pressure, flow, vacuum, tank capacity and operating duration.
Engineer the layout
Mounting, tank material, hose, reel, filtration, controls and boom.
Plan the lifecycle
Training, documentation, parts, maintenance and support after handover.
Please complete the required option groups.
Product literature
Technical documents.
Enquire about this product →
Product enquiry
Tell us what the unit needs to do.
Include the material, operating environment and any known pressure, flow, vacuum, tank or mounting requirements.
