Tank Cleaning Systems
Werner internal vessel-cleaning systems bring high-pressure pump units, controlled cleaning heads, positioning equipment, valves and automation together as a modular solution. From a simple manual hose guide to a process-integrated, gas- or pressure-tight lance system, each configuration is selected around vessel geometry, residue, access and operating conditions - for repeatable cleaning in chemical, petrochemical, pharmaceutical, plastics and heavy-industry plants.
Product overview
Built to endure. Engineered to perform.
Cleaning a reactor, autoclave, agitator vessel or storage tank is not simply a matter of adding more pressure. Vessel openings, internal components, residue, cleaning medium, hazardous-area requirements and process downtime all determine the right system.
Coverage engineered into the head
The water-driven TWK cleaning head uses two opposing, off-axis nozzles. Rotor movement combined with rotation on the vertical axis carries the water jets across the internal surface, including difficult-to-reach areas. The KBR cleaner provides an electrically or pneumatically driven option for smaller vessels.
Position the cleaning action where it counts
Manual hose guides, rigid-tube RPE devices, hose-guiding SPE systems, tele-arms and telescopes provide flexible positioning. Automatic reel systems suit multiple vertical cleaning positions and lifting lengths up to 25 m; fixed lance systems provide controlled positioning over approximately 6-7 m, with greater travel possible in specific vertical applications.
From stand-alone cleaning to process integration
Systems can be mobile or permanently installed, manually operated or electronically programmed, and integrated with plant process control. Gas-tight, pressure-tight and explosion-proof configurations are available where the application requires them. Werner South Africa helps define a complete system that is fit for difficult plant conditions at home and demanding vessel-cleaning work internationally.
Modular selection of pump unit, cleaning head, positioning system, valves and controls
TWK tank-cleaning head with controlled horizontal and vertical coverage
Manual, electric, pneumatic, hydraulic and water-powered drive options
Mobile, floor-, wall-, ceiling- or vessel-mounted installations
Automatic reel systems with lifting lengths up to 25 m
Lance systems with approximately 6-7 m travel in standard applications
Gas-tight, pressure-tight and explosion-proof options for suitable applications
How the system is defined
Performance starts with the duty.
Werner technical sales matches the complete unit to the material, environment, mounting and working cycle. Final specifications remain subject to engineering confirmation.
- Controlled multi-axis cleaning reaches internal vessel surfaces
Configuration options
A complete working system, not a catalogue code.
Select the points you want to discuss. Your choices will be carried into the product enquiry as a grouped configuration brief.
Define the duty
Material, pipe or surface, environment, access, distance and working cycle.
Set the performance
Pressure, flow, vacuum, tank capacity and operating duration.
Engineer the layout
Mounting, tank material, hose, reel, filtration, controls and boom.
Plan the lifecycle
Training, documentation, parts, maintenance and support after handover.
